Waveshare SIM7600E-H 4G LTE Cat-1 HAT for Raspberry Pi (3G/2G/GNSS)
Waveshare SIM7600E-H 4G LTE Cat-1 HAT for Raspberry Pi (3G/2G/GNSS)
KShs 17,400.00
Free delivery anywhere in Kenya
LTE Cat-1 / 3G / 2G communication and GNSS positioning HAT for Raspberry Pi, with USB and UART interfaces, SIM and TF card slots and audio for calls.
Product Overview
A feature-rich cellular HAT for Raspberry Pi providing LTE Cat-1, 3G and 2G communication together with GNSS positioning. It supports dial-up, phone calls, SMS, TCP, UDP, HTTP and FTP, and can also be driven from other hosts such as Arduino or STM32 over UART.
Key Features
| Feature | Benefit |
|---|---|
| LTE Cat-1 / 3G / 2G | Falls back to older networks where 4G is weak |
| GPS, BeiDou, GLONASS and LBS | Positioning even in difficult conditions |
| Calls, SMS, TCP, UDP, DTMF, HTTP and FTP | Voice, messaging and internet protocols built in |
| USB and CP2102 USB-to-UART | Connect to a Pi or a PC over USB |
| UART pins for Arduino / STM32 | Also works with microcontrollers |
| Audio jack for voice calls | Make and answer calls with a headset |
| SIM slot (1.8 V / 3 V) and TF card slot | Standard SIMs plus local storage |
| Status LEDs | See network and power state at a glance |
Applications
| Application Area | Example Projects |
|---|---|
| IoT gateways | Sending sensor data where there is no Wi-Fi |
| Vehicle tracking | GNSS positions sent over mobile data |
| Remote monitoring | Water tanks, generators, solar sites and farms |
| Alerts | SMS notifications from a Raspberry Pi |
| Agriculture | Field sensors and irrigation control |
Benefits
Connect anywhere
Mobile networks reach sites far from Wi-Fi or wired internet.
Location built in
The GNSS receiver adds position data for tracking projects.
Standard control
AT commands are well documented and work from Python or any serial terminal.
Specifications
| Specification | Details |
|---|---|
| LTE speed | Up to 10 Mbps down / 5 Mbps up (Cat-1) |
| 3G (HSPA+) | Up to 42 Mbps down / 5.76 Mbps up |
| 2G bands | GSM/GPRS/EDGE 900 / 1800 MHz |
| Dimensions | 56.21 × 65.15 mm |
| Operating temperature | −30 °C to +80 °C |
Why Choose This Product?
It’s the most complete cellular option in the range: 4G with 3G/2G fallback, GNSS, voice calls and support for non-Raspberry Pi hosts.
Beginner Use Cases
- Send an SMS from a Raspberry Pi
- Read your GPS position
- Log location to a file
- Make a remote temperature alert
Professional Use Cases
- Fleet and asset trackers
- Remote telemetry for utilities
- Off-grid IoT gateways
- Field-deployed data loggers
Please Note
- Raspberry Pi and SIM card are not included
- Voice calls and SMS use AT commands, with the onboard audio jack for a headset
- Also works with the NVIDIA Jetson Nano 40-pin header
Which Cellular Module Should I Choose?
- Waveshare A7670E — 4G LTE Cat-1 plus GNSS positioning, with LTE and GNSS antennas in the box.
- Waveshare SIM7600E-H — 4G LTE Cat-1 with 3G/2G fallback, GNSS and a headphone jack for voice calls.
- SIM808 — 2G GSM/GPRS with GPS and Bluetooth for low-data trackers; check 2G coverage where you will deploy.
